Distal femur fractures



SH2SH1Distal Femur SH2 ORIF



Anatomy



Distal femur physis

- fuses 14 in girls / 16 in boys

- 70% of growth of femur

- 405 of growth of lower limb

- 1 cm per year



Physis has three main undulatations



Epidemiology



Average age 10 - 11 years

Falls / MVA

NAI - distal femur fractures prior to walking



Associated injuries



Incidence of ACL injuries



Types



Distal femur fractures not involving physis

Growth plate fractures - Salter Harris Type II most common 60%



Distal Femoral Fracture SH2 APDistal Femoral Fracture SH2 Lateral

Salter Harris Type I



SH2SH2

Salter Harris Type II



Type IIIType IIIType 3

Salter Harris Type III



Dis femurDis femur

Supracondylar distal femur fracture



HoffaHoffa



Management



Undisplaced



Extension plaster 6 weeks



Supracondylar without physeal involvement



dis femurdis femurDis femur



Options



Plate

Antegrade flexible nails



dis femurDis femurdis femur



Salter Harris Type I / Type II with minimal metaphyseal bone



SH1SH1



Option



Reduce

Cross K wires - can be unstable and lose position



Technique



SH1SH1SH1



Salter Harris Type II



Distal Femur Salter Harris 2Distal Femur Salter Harris 2



Technique



Large Thurston-Holland fragment

- physeal sparing metaphyseal screws



Block to reduction

- often medial sided periosteum

- may need small medial subvastus / anteromedial approach



Distal Femur SH2 ORIFDistal Femur SH2 ORIFDistal Femur SH2 Lateral



SH2dis femurdis femur



Complications



Complete growth arrest



SH1SH1LLD



Monitor 6 monthly

- plot short and long leg lengths on Mosely chart

- distal femur contributes 9 mm / year



LLDLLD



Manage LLD as per predicted difference

- usually contralateral femoral epiphysiodesis if < 5 mm

- may need femoral lengthening / ISKD on maturity if > 5 mm



Partial growth arrest / angular deformity



SH2Dis femurDis femur



Management



CT / MRI - assess percentage of bony bridge



Bony bridge < 50%

- excision and fat graft

- manage angular deformity with 8 plates / osteotomy



Bony bridge > 50%

- hemi-epiphysiodesis

- may need correction of LLD and angular deformity

- opening wedge femoral osteotomy



Angulardis femurdis femur
