Operative management



Schottle MPFL TTO



Indications



Recurrent disabling patella instability



Options



MPFL reconstruction

Tibial tuberosity osteotomy

Trochleoplasty

Derotation osteotomy



Results



MPFL v MPFL + TTO



Vivek et al KSSTA 2023

- systematic review of isolated MPFL v MPFL + TTO

- 31 studies and 1400 patients

- isolated MPFL: mean Kujala 85, redislocation 3%

- MPFL + TTO: mean Kujala score 84, redislocation 3%



TTTG > 20



Gueval et al OJSM 2023

- systematic review of isolated MPFL v MPFL + TTO with TTG > 20

- 13 studies and 400 knees

- no difference in redislocation rates or complications

- improved Kujala scores with isolated MPFL



MPFL reconstruction



Indication



Mild patella instability

TTTG < 20



MPFL MPFL



Options



MPFL reconstruction - use graft to connect femur to the patella



Medial quadriceps tendon femoral ligament (MQTFL) - use graft to connect femur to the quadriceps tendon



Combined



MPFL MQTFL



MPFL technique



MPFL MPFL

Patella inlay with tunnel/screw versus patella onlay technique with suture anchors



Vumedi MPFL reconstruction with hamstring autograft video



Patella

- expose medial patella

- identify superior half of patella

- fixate graft with screws / bone anchors

- identify layer between medial retinaculum and capsule

- pass graft superficial to capsule



Schottle's Point

- radiographic landmark for isometric insertion point MPFL on femur

- 1 mm anterior posterior cortex

- 2 mm distal to MFC origin

- proximal to Blumensaat's line



Schottle Schottle



Femur

- dissection down to bone

- protect saphenous nerve

- use xray to find Schottle's point

- aim femoral pin anterior to Blumensaat's line / 30o

- drill for size of graft

- pass graft and fixate with screw



MPFL MPFL MPFL



Results



MPFL reconstruction



Schneider et al AJSM 2016

- systematic review of isolated MPFL for recurrent patella instability

- mean postoperative Kujala score 86

- 84% return to sports

- recurrent instability 1%

- positive apprehension sign 4%

- reoperation rate of 3%



Autograft versus allograft



Perez-Espina et al J Pediatr Orthop 2026

- systematic review of MPFL autograft v allograft in adolescents

- 23 studies and 800 knees

- autograft: recurrent dislocation 6%, return to sport 71%

- allograft: recurrent dislocation 9%, return to sport 91%



Patella tunnel versus suture anchor fixation



Yoon et al OJSM 2020

- 46 MPFL reconstruction using transosseous tunnel versus suture anchors on patella

- transosseous tunnel: 2 patella fractures, 1 redislocation

- suture anchor fixatiion: 0 patella fracture, 0 redislocation



MQTFL reconstruction



Technique






Mqtfl MQTLF



Youtube MQTFL technique video



Arthrex MQTFL technique video



Autograft / allograft

- pass through midline incision in quads tendon above patella

- pass to incision at superolateral border patella

- pass layer 2/3

- attach to Schottle's point



Results



Migliorini et al Eur J Orthop Surg 2026

- systematic review of MQTFL for 300 knees

- recurrent instability 6%

- reoperative rate 2%



Complications



Anterior femoral tunnel



Patella Instability MPFL and TTT MPFL



Infection



Infection MPFL



Patella fracture



Fracture Fracture Fracture



Tibial Tuberosity Osteotomy



TTO TTO TTO



Indication



TTTG > 20

Severe lateral patella subluxation



patella patella



patella patella



Technique



Vumedi tibial tuberosity osteotomy v+ MPFL video



Tibial tuberosity osteotomy

- incision midline over tibial tuberosity

- expose tibial tuberosity medial and laterally

- identify and protect patella tendon insertion

- often need lateral release to reduce patella

- insert K wires to guide osteotomy

- some obliquity to allow antero-medialisation

- osteotomy 1 cm deep, 6 cm long



Lateral release

- usually need large lateral release in severe cases



Distalization

- can resect 1 cm off the tibial bone block

- allows distalization of the tibial tuberosity osteotomy

- pulls tibia down into the groove



TTO TTO TTO

Distalization by resecting 1 cm from bone block and distalizing tibial tuberosity



TTO TTO

Post tibial tuberosity osteotomy with distalization



Fixation

- secure with 2 or 3 bicortical 4.5 mm fully threaded screws with lag screw technique

- +/- distal plate over osteotomy to minimize stress fracture risk



TTO TTO TTO



MPFL reconstruction

- standard technique as above

- hamstring / medial patella anchors / femoral fixation Schottle's point



MPFL Reconstruction 1 MPFL Reconstruction 2



Patella femoral chondral defects



Consider cartilage regeneration procedure

- microfracture / MACI / de novo / AMIC



www.boneschool.com/knee-cartilage-defects



Patella instability cartilage loss Patella AMIC



Results



patella TTO TTO



Complications



Berk et al Orthop J Sports Med 2023

- review of 344 TTO

- stiffness 16%

- superficial infection 8%

- hemarthrosis 6%



Periprosthetic fracture



TTO TTO TTO



TTO TTO TTO



Plate Plate

Use of distal plate to avoid stress riser



Trochleoplasty



trochleoplasty trochleoplasty trochleoplasty



Indication



Trochlea dysplasia



Trochlea dysplasia crossover Trochlea dysplasia



Options



1. Sulcus deepening of trochlea - Dejour



Trochleoplasty



2. Lateral condyle elevation and bone graft - recreate groove



Trochleoplasty Trochleoplasty



3. Lateral condyle / lateral bump reduction



Techniques



Vumedi Dejour sulcus deepening trochleoplasty video



Arthroscopy techniques sulcus deepening trochleoplasty + MPFL



Arthrex trochleoplasty techniques



Results



Trochleoplasty v Tibial tuberosity osteotomy



Bedeir et al J Knee Surg 2025

- systematic review of trochleoplasty v TTO in setting of trochlea dysplasia

- 10 studies and 360 knees

- TTO: 21/230 (9%) recurrent instabilty

- trochleoplasty: 3/132 (2%) recurrent instability



Femoral derotation osteotomy



Indication



Increased femoral anteversion



Results



Zhang et al KSSTA 2020

- 144 patients treated with MPFL + TTO

- poorer outcome scores with femoral anteversion > 30 degrees



Wang et al KSSTA 2024

- systematic review of FDRO + MPFL

- better outcome scores with combined surgery in setting of increased femoral anteversion

- no nonunion



Tibial Derotation Osteotomy



Indication



Excessive external tibial torsion > 30 degrees

1 / 5000 people



Tibial Derotation Osteotomy Tibial Derotation Osteotomy Tibial Derotation Osteotomy Lateral



Results



Drexler et al KSSTA 2014

- tibial derotation osteotomy for 15 knees with external tibial torsion and patella instability

- mean age 34, mean preoperative ETT was 62 degrees

- 2 nonunions - one bone grafted, one revised to TKA



Ferreira et al J ISAKOS 2024

- systematic review of derotation tibial osteotomy for PFJ instability

- 8 studies and 245 knees

- 94% patient satisfaction
