ACL Rupture

Issues



1.  More common recently

- more high level sport



2.  High risk of reinjuring knee from instability

- can suffer permanent severe chondral and meniscal damage



3.  Risk of physeal arrest high if bone block across physis

- risk is growth arrest with ACL reconstruction



Epidemiology



Hemarthrosis

- 60% children have ACL tear



ACL tear

- 20% have mensical injuries



Most occur within 6-12 months of skeletal maturity



Management



Non operative



Issues



1. Non complicance children / young adolescents high

- high risk of chondral and meniscal damage



2.  Best to delay surgery if able til close to maturity

- avoid growth arrests



Technique



No sport / ACL brace / ACL rehabilitation

- until 2 years from skeletal maturity



Results



Aichroth et al JBJS Br 2002

- 60 children with ACL deficient knees 1980-1990

- average age 12.5 years

- 23 patients treated conservatively, NHx was severe instability & poor knee function

- 15 knees had meniscal tear, 3 osteochondral fractures, 10 knees developed OA changes

- 37 knees with Hamstring ACL reconstruction average age 13 years

- no physeal arrest and satisfactory results in 80%



Operative



Indications



1.  Meniscal tear / displaced / blocking extension



2.  Failure non operative treatment

- continued instability

- high risk of chondral damage



3.  Within 2 years of maturity



Problems



Growth arrest / angular deformity / LLD



Predicting growth potential



Skeletal age with Greulich-Pyle atlas

Anderson table predict growth remaining using height and growth potential



Options



Extra-articular / over the top

Intra-articular

- physeal sparing

- partial transphyseal

- transphyseal



Extra-articular / Over the Top



Indications

- > 5 years to maturity

- avoid physeal injury



Procedures



McIntosh procedures

- ITB over the top

- combined intra-articular and extra-articular reconstruction



Technique Kocher JBJS Am 2005



Harvest

- lateral incision

- entire ITB taken

- left attached distally, detached proximally

- tubularised with no 5



Arthroscopy performed

- removal of ACL stump

- minimal notchplasty to avoid injury perichondral ring distal femur



Femur

- ITB passed extra-articular around lateral femoral condyle

- over the top position

- passed out anteromedial portal



Tibia

- 4 cm incision over anteromedial tibia

- clamp passed into knee under intermeniscal ligament

- groove for tendon made in epiphysis in this area

- graft passed through



Fixation femur

- knee 90o and foot ER 15o

- sutured to lateral intermuscular septum / extra-articular



Fixation tibia

- 20o flexion

- II used to assess location of growth plates

- groove made in proximal tibia

- graft sutured in place



Post op

- TWB 6/52

- restricted ROM 0 - 90o first 2 weeks



Results



Kocher et al JBJS Am 2005

- 44 patients average age 10

- ITB extra-articular physeal sparing / McIntosh modification

- 2 revisions for graft failure at 5 and 8 years

- no angular or leg length deformity

- excellent IKDC and Lysholm scores

- pivot shift normal in 31 and nearly normal in 11



Intra-articular reconstruction



Indications

- < 5 years to maturity



Assessment of Bone Age



Xray right hand / Greulich-Pyle atlas

- estimate bone age

- estimate amount of growth from femur and tibia



Theory



4 strand hamstring graft



Tunnels < 5% physeal area do not cause growth disturbance

- i.e. 6 - 8 mm drill hole

- need to keep vertical to minimise area



Tunnels 7 - 9% of growth area

- if leave transphyseal tunnels empty or have bone inside

- will form physeal bars

- if place soft tissue across (i.e. graft) will not form physeal bar



Options

1.  Physeal sparing

2.  Partial transphyseal

3.  Transphyseal



A.  Physeal sparing / transepiphyseal



Technique



Avoiding tibial physis

- tunnel anterior tibial epiphysis / trans epiphyseal

- graft secured with screw post / staple into tibial metaphysis



Avoiding femoral physis

- femoral tunnel horizontal and remains in femoral epiphysis

- transphyseal

- entrance in ACL origin

- use II guidance to spare the physis

- tunnel at 90o

- secured with endobutton

- 'over the top' position



Results



Anderson et al JBJS Am 2003

- 12 immature patients

- no LLD, stable knees



B.  Partial transphyseal



Technique



Tibial tunnel transphyseal

- keep small (6 mm)

- keep vertical



Femoral tunnel as above

- over the top

- physeal sparing



C.  Transphyseal



Technique



Analogous to adult reconstruction



Preventing growth arrest

- tunnels < 7% physeal area (7mm tunnels)

- soft tissue interposition across physis

- tunnels are vertical as possible

- central in the physis to avoid angular deformity

- single pass, wash +++

- anchorage away from physis

- endobutton for femur

- short screw / staple / post for tibia

- graft only across physis



Results



Kocher et al JBJS Am 2007

- 61 knees in patient average age 14

- 3% / 2 patients revision for graft failure at 14 and 21 months postoperatively

- pivot shift normal in 51 and nearly normal in 3

- no angular or LLD

- 3 cases of arthrofibrosis requiring MUA
